Crown C-G Series Forklifts

Explore

The Crown C-G Series cushion tire forklifts are engineered for reliable performance and versatility, offering load capacities ranging from 8,000 to 12,000 pounds. These forklifts are designed to excel in various material handling environments, combining power with maneuverability, even in confined spaces.

Key Features:

  • Robust Engine Performance: Equipped with an industry-proven 3.8-liter Kubota 4-cylinder LPG engine, the C-G Series delivers powerful, long-lasting industrial performance.

  • Heavy-Duty Cooling System: An optional open core radiator and vented side panels help protect the engine and transmission from overheating, especially in heavy-use or high-temperature applications.

  • Durable Construction: Features a rugged cast iron axle and oil-cooled disc brakes, offering reduced maintenance and backed by a 5-year, 10,000-hour warranty.

  • Enhanced Hydraulic Efficiency: Increased hydraulic hose diameter improves flow, resulting in a 13% enhancement in attachment performance.

Versatility and Application Diversity:

  • Adaptable Design: The C-G Series is versatile, with a range of available attachments to fit various specialty applications, making it suitable for dock work, warehouse tasks, and manufacturing material movement.

  • Compact Maneuverability: The Box Car Model offers a tight turn radius and shorter wheelbase, ideal for navigating tight manufacturing environments or congested storage areas.

Operator Comfort and Control:

  • Ergonomic Features: Designed with a spacious operator compartment, large wide-open floorboard, large mirrors, tilt and telescoping steering wheel, and a rear handle horn standard, all contributing to reduced operator fatigue and increased productivity.

Specifications:

Model Capacity (lbs) Max Lift Height (in) Engine Type Power (LPG) Width Overall (in)
CGC35-55 8,000 – 12,000 276 3.8L LPG 92.5 HP @ 2,500 RPM 50 – 55.9

Note: Specifications may vary based on specific configurations and options.

Why Choose the Crown C-G Series?

  • Reliable Performance: The robust engine and durable components ensure consistent operation in demanding environments.

  • Versatility: With various attachments and models, including the compact Box Car Edition, the C-G Series can be tailored to diverse applications.

  • Operator Comfort: Enhanced ergonomic features reduce fatigue, promoting productivity and safety.
